Maximum workpiece diameter: mm 155 (6 inches)
Cutting feed traverse (X axis): Travel mm 300
Maximum feedrate: mm/min 2400
Workpiece indexing column traverse (Y axis): mm 160
Maximum feedrate: mm/min 1000
Blade head infeed traverse (Z axis) Maximum travel: mm 80
Maximum feedrate mm/min 1000
Workpiece rotational indexing swivel
(C axis) Travel degree ±100
Programming resolution X, Y, Z axis mm 0.00001
C axis degree 0.0001
Spindle rotational speed For 2 inch blade min-1 4000～40000
For 3 inch blade min-1 3000～30000
For 4 inch blade min-1 2000～20000
Fanuc control system with MPG
