Sony

1x Sony PFA-D100 24-Channel Direct Digital Audio Distribution Amplifier

1x Sony PFA-D100 24-Channel Direct Digital Audio Distribution Amplifier

$107.99 USD
$107.99 USD
Sale Sold out
Shipping calculated at checkout.

2 in stock
Condition
Used
Description
Tested & working, fully functional, 30-Day Guarantee!
See Photos for cosmetic condition.
Pictures are actual item being sold. Includes item only as pictured with no other parts, cables or accessories.
Item on hand and ready to ship.
See Full Item Description for details.
Specifics
Manufacturer Sony
Model Number PFA-D100
SKU 19-31837
Ref 23-41731
Item Details
Item Details
Testing: This unit was pulled from a working environment for reasons that did not include any defects or performance issues. It has been cleaned and thoroughly inspected as well as any testing possible at our warehouse has been performed. If you have any questions related to this specific unit's testing (if applicable) please ask.

Full 30-day Guarantee. We are confident enough this unit will function normally we're willing to guarantee it for a full 30 days.

Includes One (1) of Pictured Item Only as shown with no additional software, parts, cables or accessories.

Cosmetic condition is our Grade B which we consider to be Great working condition despite having some signs of use scuffs, scratches, blemishes or other cosmetic wear. Since opinions regarding cosmetics can vary we ask you use the pictures provided to determine for yourself, if you need more please ask.

Description
The PFA-D100 is a digital audio distribution amplifier and can provide up to 24 channels to digital video/audio systems. Output signals conform to the AES/EBU format with 48KHz sampling frequency. Direct interface with digital audio equipment, such as Sony D-1 and D-2 VTRs, is possible.

Key Features & Specifications
  • Conforming to the AES/EBU format with 48.0kHz sampling frequency
  • Locking to video reference AES/EBU sync signals
  • Operation standard video signals can be selected with an internal switch
  • Re-clocking digital audio signals using a reference video AES/EBU sync signal
  • Dual AC inlets
  • 2U height and 19 inch rack mountable
  • Reference Video Input: Analog video signal Black burst Composite sync Composite video
  • Digital Output: AES/EBU format, XLR-3-32 type x 24
  • -Digital Input: AES/EBU format, XLR-3-31 type x 4
  • Power Consumption: 15W (approx)
  • Power Requirements: AC-100V-120V/220V-240V, 50/60Hz
  • Four selectable distribution: Four blocks of one stereo input x 6 outputs; Two blocks of one stereo input x 12 outputs; A block of one stereo input x 24 outputs; Two blocks of one stereo input x 6 outputs and a block of one stereo input x 12 outputs; A bl
Published Specifications are available:
Click here for Data Sheet PDF
